Using a simple telescope with vertical graduations, the tree is “framed” between any two stadia hairs and the laser is fired. The diameter of the trunk at that point is calculated and displayed. Sight two further points on the trunk and the height and volume of timber between the two points is also calculated
| Products Benefits |
| • Durable construction - Long
life & reliable • Ergonomic design - easy to handle • Red dot scope - easy to aim in all light conditions • Multi function modes - easy to aim in all light • Accessories available - adaptable for multi-role options • Environmentally resistant to IP65 - suitable for use in most conditions • RS232 data I/O - fast external data collection or integration with GPS receivers • Lightweight 600g - easy to carry • 300m reflectorless range - less walking plus increased productivity |
| Uses & Functions |
| • Distance to targets • Bearing and elevation to targets • Heights of large objects • Widths between targets • Slopes and gradients • Areas and volumes • X, Y & Z coordinates • Perimeter distances |
Applications |
|---|
| • Remote Distance Measurements • GIS Data Acquisition • GPS Offsets • Utility Asset Mapping • Microwave Path Surveys • Face Profiling • Stockpile Measurements • Accident Reconstruction • Environmental Monitoring • Forensic Surveys • Ground Surface Modelling • Forestry Management |
