Refreshing a GPS Standard

In addition, this unit features a new, highly sensitive GPS receiver that acquires satellites faster and lets users track their location in challenging conditions, such as heavy foliage or deep canyons. The GPSMAP 60CSx also incorporates a barometric altimeter for extremely accurate elevation data and an electronic compass that displays an accurate heading while standing still.

Considered the mainstay among serious outdoor enthusiasts, the GPSMAP 60CSx and GPSMAP 60Cx offer a large color TFT display and turn-by-turn routing capability. Each unit comes with a blank 64 MB microSD card. Owners of these new x-series handhelds can also purchase new microSD cards that are pre-loaded with MapSource® Topo and inland lake maps, BlueChart® marine cartography, and City Navigator™ street maps.

Navigation features

Waypoint/icons: 1000 with name and graphic symbol, 10 nearest (automatic), 10 proximity

Routes: 50 reversible routes with up to 250 points each, plus MOB and TracBack modes®

Tracks: 10K point automatic track log; 20 saved tracks 500 points each let you retrace your path in both directions

Trip computer: Current speeed, average speed, resettable max. speed, trip timer and trip distance

Alarms: Anchor drag, approach and arrival, off-course, proximity waypoint, shallow water and deep water

Tables: Built-in celestial tables for best times to fish and hunt, sun and moon rise, set and location

Map datums: More than 100 plus user datum

Position format: Lat/Lon, UTM/UPS, Maidenhead, MGRS, Loran TDs and other grids, including user UTM grid only

GPS Performance

Receiver: 12 channel SiRFstar III™ high-sensitivity GPS receiver (WAAS-enabled) continously tracks and uses up to 12 satellites to compute and update your position

Acquisition times:

• Warm: < 1 sec
• Cold: <38 sec
• AutoLocate™: <45

Update rate: 1/second, continuous

GPS accuracy:

• Position: <10 meters, typical
• Velocity: .05 meter/sec steady state

DGPS (WAAS) accuracy:

• Position: <5 meters, typical
• Velocity: .05 meter/sec steady state

Protocol messages: NMEA 0183 output protocol

Antenna: Built-in quad helix receiving antenna, with external antenna connection (MCX)

Moving map features

Basemap: Detailed routable basemap with cities, highways, interstates, exit info, rivers lakes; preloaded with worldwide cities

Uploadable maps: Accepts downloaded or plug-in microSD map detail from a variety of optional MapSource media (64 MB microSD card included)

Electronic Compass feature: (GPSMAP 60CSx only)

Accuracy: +/- 2 degrees with proper calibration (typical); +/-5 degrees extreme northern and southern latitudes

Altimeter feature: (GPSMAP 60CSx only)

Resolution: 1 foot

Range: -2,000 to 30,000 feet

Elevation computer: Current elevation, resettable minimum and maximum elevation, ascent/descent rate, total ascent/descent, average and maximum ascent/descent rate

Pressure: Local pressure (mbar/inches HG)

Power

Source: Two "AA" batteries (not included)

Battery Life: 18 hours, typical; up to 30 with battery saving

Physical

Size: 2.4W x 6.1H x 1.3D inches

Weight: 7.5 oz. (213 g) est.

Display: 1.5 x 2.2 inches (38.1mm x 56mm) 256-color transflective TFT (160 x 240 pixels) (160 x 240 pixels)

Case: Waterproof to IPX-7 standards

Temp. range: 5ºF to 158ºF (-15ºC to 70ºC)

Specifications are subject to change without notice.
